Networking FTP CAT6 LSZH Cable 23AWG 500ft Blue Jacket 550MHz

Name: Networking FTP CAT6 LSZH Cable 23AWG 500ft Blue Jacket 550MHz
Brand: Integrity Cable Co., Limited
SKU: ITI-CT6F-026
Availability: InStock

Brand Name:	ITI -LINK
Model Number:	ITI-CT6F-026
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Jacket Material:

LSZH

Cable Type:

FTP

Color:

Blue

Cable Length:

500ft

Category:

Cat6

Conductor Dimensions:

0.550mm

Conductor Material:

Copper

Conductor Size:

23AWG

Packaging Details:

Inner box size: 32 cm (length) × 32 cm (width) × 18.5 cm (height) Outer box size (for packing): 39 cm (length) × 33.5 cm (width) × 34 cm (height)

Highlight:

Networking CAT6 Cable

23AWG FTP CAT6 Cable

550MHz FTP CAT6 Cable

Product Description

Wholesale Bulk FTP CAT6 LSZH Cable 23AWG 500ft Blue Jacket 550MHz High Speed Networking

Premium Performance Networking Cable

The ITI-LINK ITI-CT6F-026 FTP CAT6 LSZH Cable delivers high-performance networking in a 500-foot bulk configuration. Featuring 23AWG conductors, blue Low Smoke Zero Halogen (LSZH) jacket, and 550MHz bandwidth support, this cable is engineered for data centers, smart buildings, and industrial networks requiring reliable 10Gbps data transfer with superior EMI resistance.

Key Features

FTP (Foil Twisted Pair) shielding for robust EMI/RFI protection in high-density environments
23AWG oxygen-free copper conductors (0.550±0.005mm diameter) minimize signal loss and crosstalk
Blue LSZH jacket enhances visibility and complies with strict fire safety regulations
550MHz bandwidth with 10Gbps speed support, doubling CAT5e performance
500-foot bulk packaging optimizes shipping costs and inventory management

Technical Specifications

Attribute	Value
Cable Type	FTP
Category	CAT6
Conductor Material	Copper
Conductor Size	23 AWG
Conductor Dimensions	0.550±0.005mm
Jacket Material	LSZH
Color	Blue
Cable Length	500ft

Electrical Properties

Property	Standard	Value
Conductor Resistance at 20°C	NF EN 50289-1-2 / IEC 60189-1	≤ 9.5 Ω / 100m
Resistance unbalance within a pair	NF EN 50289-1-2/ IEC 60708	≤ 5%
Insulation Resistance	NF EN 50289-1-4 / IEC 60885-1	>1500 MΩ / 100m
Mutual capacitance	NF EN 50289-1-5 /IEC 60189-1	5600pF / 100m MAX
Characteristic impedance at 100MHz	NF EN 50289-1-11/ IEC 61156-1	100 ± 15 Ω

Applications

Enterprise & Office Networks: Supports cloud collaboration, video conferencing, and real-time data applications
Data Centers & Cloud Infrastructure: Ideal for high-density server racks and storage area networks
Industrial Automation & IoT: Connects PLCs, robotics, and IoT sensors in harsh environments
Smart Cities & Public Venues: Establishes networks for ticketing systems, surveillance cameras, and public Wi-Fi
Education & Healthcare Campuses: Supports e-learning platforms and telemedicine systems

Frequently Asked Questions

Q: What is the brand name of this product?

A: The brand name of this product is ITI-LINK.

Q: What is the model number of this product?

A: The model number of this product is ITI-CT6F-026.

Q: Where is this product manufactured?

A: This product is manufactured in SHENZHEN.

Q: What is the maximum data transfer rate of this CAT6 cable?

A: This CAT6 cable supports maximum data transfer rate of up to 10Gbps.

Q: Does this CAT6 cable come with connectors?

A: No, this CAT6 cable does not come with connectors. It is a bulk cable that needs to be terminated with connectors of your choice.
