CAT6A SFTP Cable LSZH Shielded Bulk LAN Cable For Data Center Business Industrial Networking

Name: CAT6A SFTP Cable LSZH Shielded Bulk LAN Cable For Data Center Business Industrial Networking
Brand: Integrity Cable Co., Limited
SKU: ITI-CTSF6A-018
Availability: InStock

Brand Name:	ITI -LINK
Model Number:	ITI-CTSF6A-018
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Category:

CAT6A

Operating Temperature:

-20°C To 60°C

Jacket Material:

PVC (Polyvinyl Chloride)

Color:

Purple

Bandwidth:

500 MHz

Conductor Material:

Copper

Length:

500feet

Shielding Type:

SFTP (Shielded Foiled Twisted Pair)

Packaging Details:

Inner box size: 32 cm (length) × 32 cm (width) × 18.5 cm (height) Outer box size (for packing): 39 cm (length) × 33.5 cm (width) × 34 cm (height)

Highlight:

CAT6A SFTP shielded LAN cable

LSZH bulk networking cable

industrial data center Ethernet cable

Product Description

CAT6A SFTP Cable LSZH Shielded Bulk LAN Cable For Data Center Business Industrial Networking

The INTEGRITY ITI-CTSF6A-018 CAT6A SFTP LSZH purple cable is engineered for wholesale buyers and system integrators who demand industrial-grade Ethernet performance. With 23AWG solid copper conductors, dual-layer shielding, and a LSZH purple jacket, it guarantees 10Gbps speed at 550MHz bandwidth while ensuring fire safety and EMI resistance. Offered in bulk reels for contractors and data centers, it delivers long-term reliability and cost efficiency.

Bulk 23AWG solid copper construction ensures stable signal integrity.
S/FTP shielding design protects against cross-talk, EMI, and interference.
550MHz bandwidth supports 10GBASE-T, 25GBASE-T, and 50GBASE-T future networks.
Low-smoke LSZH purple jacket complies with global building safety codes.
Optimized for data center rack cabling and industrial plant backbones.
Durable jacket withstands UV, temperature fluctuations, and chemical exposure.
Easy-to-identify purple color speeds up cable management by 30%.
Certified by UL, CE, RoHS, and CPR Dca-S2/D2/A1 standards.
Volume discounts up to 25% available for 500+ reel orders.
Custom lengths, branding, and packaging services for bulk buyers.

Technical Specifications

Construction & Electrical Properties

Construction Item	Description	Electrical Property	Value
Conductor Material	Bare Solid Copper (elongation: 19-24%)	Conductor Resistance at 20°C	≤ 9.5 Ω / 100m
OD	23 AWG	Resistance unbalance within a pair	≤ 2%
Insulation Material	PE Skin-Foam-Skin	Insulation Resistance at 20°C	>1500 MΩ / 100m
OD	1.35 ±0.01 mm	Mutual capacitance	5600 pF / 100m MAX
Average THK	0.38 mm	Capacitance unbalance pair to ground	≤ 160 pF / 100m
Color	1p: white + 2 blue stripes & blue 2p: white + 2 orange stripes & orange 3p: white + 2 green stripes & green 4p: white + 2 brown stripes & brown	Characteristic impedance at 100MHz	100 ± 15 Ω

Transmission Properties

Frequency (MHz)	Attenuation (Max) (dB/100m)	Propagation Delay (Max) (ns/100m)	Return Loss (Min) (dB)	NEXT (Min) (dB)
4	3.8	552	45	66.27
8	5.31	546.73	45	61.75
10	5.93	545.38	45	60.3
16	7.49	543	45	57.24
20	8.38	542.05	45	55.78

Applications

The INTEGRITY ITI-CTSF6A-018 CAT6A SFTP Ethernet cable is engineered for high-performance networking in mission-critical environments. Featuring 23AWG solid copper conductors, double shielding (foil and braid), and a low smoke zero halogen (LSZH) purple jacket, this cable delivers reliable 10Gbps data transmission up to 100 meters with 500MHz bandwidth.

Data Centers and Cloud Facilities - Optimized for high-density server racks, backbone cabling, and cloud storage networks. Superior shielding minimizes electromagnetic interference.
Enterprise and Commercial Networks - Supports business offices, universities, hospitals, and government facilities. LSZH jacket ensures compliance with EU CPR fire safety regulations.
Industrial and Manufacturing Applications - Supports stable connectivity for PLCs, industrial robots, IP surveillance cameras, and wireless access points.
Smart Infrastructure and IoT - Provides a reliable backbone for smart homes, IoT device integration, and AI computing clusters.

For bulk projects, contractors, and wholesale buyers, INTEGRITY offers OEM/ODM customization, volume discounts, and staggered delivery options. With advanced production capacity and CNAS-certified lab testing, INTEGRITY guarantees consistent quality and long-term reliability.
