Gray LSZH SFTP CAT7 Cable 23AWG Oxygen Free Copper Lan Cable 600MHz 1000FT

Name: Gray LSZH SFTP CAT7 Cable 23AWG Oxygen Free Copper Lan Cable 600MHz 1000FT
Brand: Integrity Cable Co., Limited
SKU: ITI-CT7SF-009
Availability: InStock

Brand Name:	ITI-LINK
Model Number:	ITI-CT7SF-009
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Jacket Color:

Gray

Cable Type:

CAT7

Jacket Material:

LSZH

Shielding Type:

SFTP

Conductor Material:

Copper

Frequency:

600MHz

Length:

1000Ft

Conductor Size:

23AWG

Packaging Details:

Color Box+Packing Box 36*36*21cm

Highlight:

Gray SFTP CAT7 Cable

SFTP CAT7 Cable 600MHz

Oxygen Free copper lan cable

Product Description

Gray LSZH SFTP CAT7 Cable 23AWG Oxygen Free Copper Lan Cable 600MHz 1000FT

Product Overview

The CAT7 SFTP 23AWG Gray LSZH Copper Cable is a high-performance Ethernet cable capable of transmitting data at 600MHz frequency. With its 1000ft length, it provides extensive coverage for demanding network setups while delivering exceptional speed for bandwidth-intensive applications.

Key Features

SFTP (Shielded Foiled Twisted Pair) construction for superior EMI protection
23AWG oxygen-free copper conductors for minimal signal loss
LSZH (Low Smoke Zero Halogen) jacket for enhanced fire safety
Supports frequencies up to 600MHz for high-speed data transfer
Ideal for 10Gbps networks and bandwidth-intensive applications
Professional gray color for easy identification in network environments

Technical Specifications

Cable Type:

CAT7 LAN Cable

Conductor Material:

Oxygen-free copper

Conductor Size:

23AWG

Shielding Type:

SFTP (Shielded Foiled Twisted Pair)

Jacket Material:

LSZH (Low Smoke Zero Halogen)

Frequency:

600MHz

Length:

1000FT

Color:

Gray

Construction Details

Construction Item	Description	Electrical Property	Specification
Conductor	Bare Solid Copper (elongation: 19-24%)	Conductor Resistance at 20°C	≤ 9.5 Ω / 100m
OD	23 AWG	Resistance unbalance within a pair	≤ 2%
Insulation	PE Skin-Foam-Skin	Insulation Resistance at 20°C	>1500 MΩ / 100m
OD	1.33 ±0.01 mm	Mutual capacitance	5600 pF / 100m MAX

Transmission Properties

Frequency (MHz)	Attenuation (Max) dB/100m	Propagation Delay (Max) ns/100m	Return Loss (Min) dB	NEXT (Min) dB
4	3.74	552	23.00	78.0
100	19.20	538	20.10	72.40
600	50.10	536	17.30	60.70
1000	66.93	535	17.10	57.40

Applications

This high-performance CAT7 cable is ideal for:

Data centers requiring high-speed connectivity
Enterprise network infrastructure
Industrial environments with EMI concerns
High-bandwidth applications (4K video streaming, cloud computing)
Office buildings requiring reliable network connections
Residential installations needing future-proof cabling

Frequently Asked Questions

What is the brand name of the SFTP CAT7 cable?

The brand name is ITI-LINK.

What is the model number of the ITI-LINK SFTP CAT7 cable?

The model number is ITI-CT7SF-009.

Where is the ITI-LINK SFTP CAT7 cable manufactured?

The cable is manufactured in SHENZHEN.

What is the maximum speed supported by the ITI-LINK SFTP CAT7 cable?

The cable supports data transfer speeds of up to 10Gbps.

What is the difference between SFTP and UTP cables?

SFTP cables have an extra layer of shielding to protect against electromagnetic interference, making them more suitable for environments with high interference levels compared to unshielded UTP cables.
