| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT7SF-007 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
This CAT7 SFTP 23AWG 600MHz network cable delivers high-speed data transfer up to 10Gbps over 100 meters, making it ideal for demanding residential and commercial applications. Backward compatible with Cat6/Cat5e equipment, it features superior shielding against interference and meets strict CPR safety standards.
| Cable Type | CAT7 Ethernet Cable |
| Frequency | 600MHz |
| Length | 1000Ft |
| Jacket Color | Gray |
| Conductor Material | Copper (23AWG) |
| Jacket Material | PVC |
| Shielding Type | SFTP |
| Component | Specification |
|---|---|
| Conductor | Bare solid copper (23AWG), elongation 19-24% |
| Insulation | PE Skin-Foam-Skin, 1.33 ±0.01 mm OD |
| Pair Shield | Polyester/Aluminium (PET/ALU), ≥115% coverage |
| Outer Jacket | PVC, 8.1 ± 0.2mm OD, gray color |
| Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m |
| Resistance Unbalance | ≤ 2% |
| Dielectric Strength | 1.00KV DC or 0.7 KV AC for 1 min (no breakdown) |
| Insulation Resistance | >1500 MΩ / 100m |
| Mutual Capacitance | 5600pF / 100m MAX |
This high-performance CAT7 cable is ideal for:
