| Brand Name: | ITI-LINK |
| Model Number: | ITI-CTSF8-021 |
| MOQ: | 1000pcs |
| Price: | 50$-100$ |
| Payment Terms: | T/T |
| Supply Ability: | 800pcs/day |
| Construction Item | Description | Electrical Property | Value |
|---|---|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 5.6 Ω / 100m |
| Conductor OD | 22 AWG | Resistance unbalance within a pair | ≤ 0.2% |
| Insulation Material | PE Skin-Foam-Skin | Insulation Resistance at 20°C | >1500 MΩ / 100m |
| Insulation OD | 1.62 ±0.01 mm | Mutual capacitance | 5600 pF / 100m MAX |
| Jacket Material | LSZH, 60P, -20~75℃ | Characteristic impedance at 100MHz | 100 ± 15 Ω |
| Frequency (MHz) | Insertion Loss (db) | NEXT (db) | Return Loss (db) | PSNEXT (db) |
|---|---|---|---|---|
| 1 | 3.0 | 73.5 | 19.1 | 62.0 |
| 100 | 5.2 | 40.5 | 18.0 | 37.1 |
| 1000 | 17.5 | 19.3 | 8.0 | 15.9 |
| 2000 | 26.2 | 9.8 | 8.0 | 6.0 |
