| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT6SF-04 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Parameter | Value |
|---|---|
| Shielding Type | SFTP |
| Maximum Frequency | 250MHz |
| Jacket Material | PVC |
| Conductor Size | 23AWG |
| Conductor Material | Copper |
| Cable Type | CAT6 |
| Maximum Data Rate | 10Gbps |
| Component | Specification |
|---|---|
| Conductor | Bare solid copper (23AWG) |
| Insulation | HDPE, 1.14 ±0.05 mm OD |
| Shielding | Polyester/Aluminium (PET/ALU), ≥115% coverage |
| Jacket | PVC, 7.2 ±0.2 mm OD, black |
| Frequency (MHz) | Attenuation (Max dB/100m) | NEXT (Min dB) | PS NEXT (Min dB) |
|---|---|---|---|
| 4 | 3.78 | 66.27 | 63.27 |
| 100 | 19.8 | 45.3 | 42.3 |
| 250 | 32.85 | 39.33 | 36.33 |
