23AWG Copper Conductor Cat6 SFTP Cable PVC Jacket for 10Gbps High-Speed Data Transmission

Name: 23AWG Copper Conductor Cat6 SFTP Cable PVC Jacket for 10Gbps High-Speed Data Transmission
Brand: Integrity Cable Co., Limited
SKU: ITI-CT6SF-07
Availability: InStock

Brand Name:	ITI-LINK
Model Number:	ITI-CT6SF-07
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Conductor Material:

Copper

Maximum Data Rate:

10Gbps

Cable Type:

CAT6

Jacket Material:

PVC

Maximum Transmission Distance:

500Feet

Shielding Type:

SFTP

Conductor Size:

23AWG

Maximum Frequency:

250MHz

Packaging Details:

Inner box size: 32 cm (length) × 32 cm (width) × 18.5 cm (height) Outer box size (for packing): 39 cm (length) × 33.5 cm (width) × 34 cm (height)

Highlight:

23AWG Cat6 SFTP Cable

PVC Jacket Cat6 SFTP Cable

10Gbps Cat6 SFTP Cable

Product Description

23AWG Copper Conductor Cat6 SFTP Cable PVC Jacket for 10Gbps High-Speed Data Transmission

Premium Networking Solution

The ITI-LINK CAT6 SFTP Cable (Model: ITI-CT6SF-07) is engineered for high-speed data transmission across diverse networking applications. Manufactured in Shenzhen, this cable delivers reliable performance over extended distances.

Key Features

23AWG copper conductor - Provides superior conductivity and signal strength for dependable network performance
SFTP shielding - Offers exceptional protection against electromagnetic interference (EMI) and radio frequency interference (RFI)
100-meter transmission distance - Ideal for LAN connections and structured cabling systems
White PVC jacket - Durable protection with easy identification in complex cabling environments
250MHz maximum frequency - Supports data rates up to 10Gbps for bandwidth-intensive applications

Technical Specifications

Cable Type: CAT6 SFTP Cable

Maximum Frequency: 250MHz

Shielding Type: SFTP

Maximum Data Rate: 10 Gbps

Conductor Material: Copper

Jacket Material: PVC

Conductor Size: 23AWG

Construction Details

Construction Item	Description	Electrical Property
Conductor	Bare Solid Copper (elongation: 19-24%)	Conductor Resistance at 20°C ≤ 9.5 Ω/100m
OD	23 AWG	Resistance unbalance within a pair ≤ 2%
Insulation	Material: HDPE, OD: 1.14 ±0.05 mm	Insulation Resistance >1500 MΩ/100m
Color	Color-coded pairs with white stripes	Characteristic impedance at 100MHz: 100 ± 15 Ω

Transmission Properties

Frequency (MHz)	Attenuation (Max dB/100m)	Propagation Delay (MAX ns/100m)	Return Loss (Min dB)	NEXT (Min dB)
4	3.78	552	23.01	66.27
100	19.8	537.6	20.11	45.3
250	32.85	536.28	17.32	39.33

Applications

This high-performance cable is ideal for:

Enterprise networks and data centers
High-speed data transfer (up to 10Gbps)
4K video streaming and online gaming
Connecting computers, printers, servers, routers, and switches
Both indoor and outdoor installations

Frequently Asked Questions

Q: What is the brand of this SFTP CAT6 Cable?

A: The brand of this cable is ITI-LINK.

Q: What is the model number of this cable?

A: The model number is ITI-CT6SF-07.

Q: Where is this cable manufactured?

A: This cable is manufactured in Shenzhen.

Q: What is the length of this cable?

A: The standard length is 500 feet.
