White CAT6A 500FT 23AWG 10Gbps Network Cable Ethernet Cable For Network

Brand Name:	ITI -LINK
Model Number:	ITI-C6AU-014
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Transmission Speed:

10Gbps

Frequency Rating:

500 MHz

Conductor Size:

23 AWG

Connector Type:

RJ45

Shielding Type:

UTP

Jacket Material:

PVC,LSZH

Conductor Material:

Copper

Insulation Color:

White

Packaging Details:

Inner box size: 32 cm (length) × 32 cm (width) × 18.5 cm (height) Outer box size (for packing): 39 cm (length) × 33.5 cm (width) × 34 cm (height)

Highlight:

White CAT6A bulk Ethernet cable 500FT

23AWG white network cable

10Gbps UTP CAT6A cable

Product Description

White CAT6A 500FT 23AWG 10Gbps Network Ethernet Cable

INTEGRITY ITI-CT6SF-014 UTP CAT6A 500FT white LSZH bulk cable is designed for installers, system integrators, and distributors requiring certified CAT6A UTP cable with CPR B2ca s1a d1 a1 compliance. This high-performance cable supports 10Gbps over 100 meters and 500MHz bandwidth, meeting next-generation network demands while offering LSZH (low smoke zero halogen) safety for EU projects.

Key Features

EU CPR B2ca s1a d1 a1 LSZH certified white jacket ideal for hospitals, data centers, and public buildings
High performance UTP CAT6A 500MHz rated for 10Gbps, 4K streaming, cloud services, and high-density Wi-Fi access points
Precision 23AWG oxygen-free copper for reduced attenuation, improved return loss, and stable NEXT characteristics
500FT bulk reel optimized for wholesale orders, reduced handling, and lower freight per meter for large projects
Factory QC 100% electrical testing ensures every reel meets attenuation, NEXT, and return loss thresholds
Commercial ready CE CPR marked with custom pallet labeling and volume discount capability
5-year warranty and product traceability simplifies procurement and support for integrators

Technical Specifications

Construction Item	Description	Electrical Properties
Conductor	Material: Oxygen-Free Bare Solid Copper Elongation: ≥15% OD: 23AWG	Single Conductor DC Resistance,Max,20℃: 9.5Ω/100m Conductor DC Resistance Imbalance,Max,20℃: ≤2% Pairs DC Resistance Imbalance,Max,20℃: ≤4%
Insulation	Material: HDPE 8303 OD: 1.01±0.02 Average THK: 0.21mm	Delay Skew,1-250MHz,Max: 45ns/100m Velocity of Propagation: 69% Insulation Resistance(CD/CD),DC100-500V,Min: 5000MΩ.km
Color	1p: white + 2 blue stripes & blue 2p: white + 2 orange stripes & orange 3p: white + 2 green stripes & green 4p: white + 2 brown stripes & brown	Pair To Ground Capacitance Unbalance,Max,0.8KHz∕1KHz: 160pF/100m Dielectric Strength(CD/CD):2.5KV DC for 2 seconds or 1KV DC for 1 minute: No Breakdown
Pair Twist	Lay & Direction: 1p:S=15.5mm(26%) 2p:S=11.0mm(19%) 3p:S=14.0mm(24%) 4p:S=12.5mm(21%)	Mechanical Property insulation elongation before aging: ≥ 300% tensile strength before aging: ≥16 MPa
Jacket	Material: LSZH Hardness: 81A±3A OD: 7.0±0.5mm Average THK: 0.7mm+Gear Color: according to customer requirements	jacket elongation before aging: ≥ 150 % tensile strength before aging: ≥10.5 MPa elongation after aging: ≥ 125 % tensile strength after aging: ≥ 10 MPa

Applications

Data centers and cloud colocation: Horizontal trunking and top-of-rack cabling using UTP CAT6A 10Gbps infrastructure
Healthcare and cleanroom wiring: LSZH white jacket meets hygiene and fire safety requirements for hospitals and labs
Smart buildings and commercial complexes: Supports IoT sensors, Wi-Fi 6 APs, and smart building backbone
Industrial network rooms: Ideal for non-EMI controlled industrial environments
ISP and campus backbone: Reduces cost per meter and simplifies large-scale rollouts
