| Brand Name: | ITI -LINK |
| Model Number: | ITI-CTSF7A-013 |
| MOQ: | 1000pcs |
| Price: | $50–$100 |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Construction Item Description | Electrical Property |
|---|---|
|
Conductor Material: Bare Solid Copper (elongation: 19-24%) OD: 23AWG |
Conductor Resistance at 20°C: ≤ 9.5 Ω / 100m Resistance unbalance within a pair: ≤ 2% |
|
Insulation Material: PE Skin-Foam-Skin OD: 1.45 ±0.01 mm Average THK: 0.42 mm Color: 1p: white + 2 blue stripes & blue 2p: white + 2 orange stripes & orange 3p: white + 2 green stripes & green 4p: white + 2 brown stripes & brown |
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V: >1500 MΩ / 100m Mutual capacitance: 5600 pF / 100m MAX Capacitance unbalance pair to ground at 800Hz or 1 kHz: ≤ 160 pF / 100m Characteristic impedance at 100MHz: 100 ± 15 Ω Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min: No breakdown |
|
Pair Twist Lay & Direction: 1p: S=19.0 mm (28%) 2p: S=23.5 mm (31%) 3p: S=21.5 mm (33%) 4p: S=25.0 mm (36%) |
Mechanical Property Insulation elongation before aging: ≥ 300% Tensile strength before aging: ≥12 MPa Elongation after aging: ≥ 150 % Tensile strength after aging: ≥10.5 MPa |
|
Inner Assemble Lay: S=90 ± 5 mm Direction: according to the drawing |
Jacket elongation before aging: ≥ 150 % Tensile strength before aging: ≥ 13.5 MPa Elongation after aging: ≥ 125 % Tensile strength after aging: ≥ 12.5 MPa |
