| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT5SF-011 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Parameter | Specification |
|---|---|
| Product Name | CAT5E SFTP 24 AWG 500Ft 100MHz Purple PVC Jacket Shielded Cable |
| Frequency | 100MHz (Expandable to 350MHz) |
| Conductor Material | Bare Solid Copper |
| Cable Shielding | SFTP |
| Jacket Color | Purple |
| Conductor Gauge | 24 AWG |
| Jacket Material | PVC |
| Cable Length | 500FT (305m) |
| Cable Type | CAT5E |
| Component | Specification |
|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) |
| Conductor OD | 24 AWG |
| Insulation Material | HDPE 8303 |
| Insulation OD | 0.90 ± 0.02 mm |
| Pair Colors | 1p: White/Blue, 2p: White/Orange, 3p: White/Green, 4p: White/Brown |
| Outside Shield | Polyester film/Aluminium Foil (PET/ALU) |
| Jacket Material | PVC, 50P, -20~75℃ |
| Jacket OD | 6.5 ± 0.2 mm |
| Property | Value |
|---|---|
| Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m |
| Resistance Unbalance within a Pair | ≤ 2% |
| Insulation Resistance at 20°C | >1500 MΩ / 100m |
| Mutual Capacitance | 5600 pF / 100m MAX |
| Capacitance Unbalance Pair to Ground | ≤ 160 pF / 100m |
| Characteristic Impedance at 100MHz | 100 ± 15 Ω |
| Spark Test | 2000 ± 250VOC |
| Frequency (MHz) | Attenuation (Max dB/100m) | NEXT (Min dB/100m) | Return Loss (Min dB) |
|---|---|---|---|
| 4 | 4.05 | 56.27 | 23.01 |
| 10 | 6.47 | 50.30 | 25.00 |
| 16 | 8.25 | 47.24 | 25.00 |
| 20 | 9.27 | 45.78 | 25.00 |
| 100 | 21.98 | 35.30 | 20.11 |
