1000FT CAT5E UTP 24AWG Plenum Rated PVC Jacket High Speed Ethernet Cable for Wholesale

Name: 1000FT CAT5E UTP 24AWG Plenum Rated PVC Jacket High Speed Ethernet Cable for Wholesale
Brand: Integrity Cable Co., Limited
SKU: ITI-CT5U-022
Availability: InStock

Brand Name:	ITI-LINK
Model Number:	ITI-CT5U-022
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Flame Retardant Grade:

CMP

Conductor AMaterial:

Bare Copper

Color:

White

Certifications:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Jacket Material:

PVC

Frequency:

350 MHz

Application:

100Base-TX/100Base-T4/100VG-AnyLan/ATM/1000Base-

Length:

1000 Ft

Packaging Details:

Color Box+Packing Box 36*36*21cm

Highlight:

PVC Jacket UTP CAT5E Cable

1000FT Plenum Rated Ethernet Cable

24AWG UTP CAT5E Cable

Product Description

1000FT CAT5E UTP 24AWG Plenum Rated PVC Jacket High Speed Ethernet Cable

The ITI-CT5U-022 by ITI-LINK is a professional-grade 1000FT CAT5E UTP cable designed for large-scale network deployments. Featuring 24AWG conductors and a Plenum-rated (CMP) PVC jacket, this UL-certified cable delivers reliable high-speed data transfer while meeting strict fire safety standards for ventilation-sensitive environments.

Key Features

Plenum Rated (CMP): Meets UL standards for safe installation in air handling spaces
High Performance: Supports up to 100MHz bandwidth and 1Gbps data transfer
Durable Construction: PVC jacket offers superior abrasion and corrosion resistance
Optimized Conductors: 24AWG oxygen-free copper minimizes signal attenuation and crosstalk
Wholesale Efficiency: 1000FT reel reduces waste and lowers management costs
Wide Compatibility: Works with routers, switches, servers and network devices

Technical Specifications

Parameter	Value
Termination Type	TIA/EIA 568B
Frequency	350MHz
Certifications	UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Conductor Material	Copper
Conductor Size	24 AWG
Jacket Material	PVC
Length	1000 Feet
Color	White

Performance Data

Frequency (MHz)	Attenuation (Max dB/100m)	NEXT (Min dB)	Return Loss (Min dB)
4	4.05	56.27	23.01
10	6.47	50.30	25.00
20	9.27	45.78	25.00
100	21.98	35.30	20.11

Applications

This high-performance CAT5E cable is ideal for:

Enterprise network infrastructure
Data center deployments
Commercial building installations
HD video surveillance systems
VoIP telephone systems
Educational institution networks
Healthcare facility communications

Frequently Asked Questions

Q: What is the brand name of this UTP CAT5E Cable?

A: The brand name is ITI-LINK.

Q: What is the model number of this UTP CAT5E Cable?

A: The model number is ITI-CT5U-022.

Q: What is the maximum data transfer speed supported?

A: This cable supports data transfer speeds of up to 1 Gigabit per second.

Q: Is this cable suitable for outdoor installation?

A: No, this cable is designed for indoor use.

Note: All specifications are subject to change without notice. Please verify current specifications before ordering.
