| Brand Name: | ITI-LINK |
| Model Number: | ITI-C6AU-005 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Parameter | Value |
|---|---|
| Conductor Size | 23 AWG |
| Category | CAT6A |
| Conductor Material | Copper |
| Jacket Color | Yellow |
| Jacket Material | PVC |
| Frequency | 500MHz |
| Length | 1000FT (305 meters) |
| Cable Type | UTP |
| Property | Value |
|---|---|
| Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | ≤ 5% |
| Insulation Resistance | >1500 MΩ / 100m |
| Mutual capacitance | 5600pF / 100m MAX |
| Characteristic impedance at 100MHz | 100 ± 15 Ω |
