| Brand Name: | ITI-LINK |
| Model Number: | ITI-CTF6A-005 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs/day |
| Product Attribute | Value |
|---|---|
| Product Name | Cat6A Ethernet Cable |
| Category | CAT6A |
| Conductor Size | 23 AWG |
| Cable Type | FFTP |
| Insulation Material | HDPE |
| Jacket Material | LSZH |
| Length | 1000ft (305m) |
| Color | Green |
| Frequency | 500MHz |
| Construction Item | Description |
|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) |
| Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m |
| Insulation Material | PE Skin-Foam-Skin |
| Insulation Resistance | >1500 MΩ / 100m |
| Jacket Material | LSZH |
| Jacket Color | Green |
| Frequency (MHz) | Attenuation (Max dB/100m) | Return Loss (Min dB) | NEXT (Min dB) |
|---|---|---|---|
| 4 | 3.8 | 23.01 | 66.27 |
| 100 | 19.13 | 20.11 | 45.3 |
| 500 | 45.26 | 17.3 | 34.82 |
