Wholesale 10Gbps IEC60332-1 CAT 6A F FTP 23AWG LSZH Cable 500MHz Solid Twin Cable

Name: Wholesale 10Gbps IEC60332-1 CAT 6A F FTP 23AWG LSZH Cable 500MHz Solid Twin Cable
Brand: Integrity Cable Co., Limited
SKU: ITI-CTF6A-004
Availability: InStock

Brand Name:	ITI-LINK
Model Number:	ITI-CTF6A-004
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	1000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Cable Type:

FFTP

Frequency:

500MHz

Length:

1000Ft

Color:

Gray

Conductor Size:

23 AWG

Category:

CAT6A

Insulation Material:

HDPE

Jacket Material:

LSZH

Packaging Details:

Wooden shaft packaging 40*26*20cm Outer box size：42*42*22cm

Highlight:

10Gbps cat 6a f ftp

23AWG cat 6a f ftp

500MHz f ftp cat6a

Product Description

Wholesale 10Gbps IEC60332-1 CAT 6A F FTP 23AWG LSZH Cable 500MHz Solid Twin Cable

Product Overview

The ITI-CTF6A-004 FFTP Cat6A 23AWG Cable is a 1000Ft networking solution engineered for peak performance. Featuring HDPE (High-Density Polyethylene) insulation for Cat6A-level electrical stability, this cable supports 500MHz frequency and 10Gbps speeds. The solid twin-cable design with FFTP (Foil Foil Twisted Pair) shielding minimizes crosstalk and EMI, making it ideal for high-bandwidth applications like data centers and industrial automation.

Key Features

Premium Construction: 23AWG solid bare copper conductors with PE Skin-Foam-Skin insulation
Advanced Shielding: Dual-layer foil shielding (FFTP) for superior EMI protection
Safety Compliance: LSZH (Low Smoke Zero Halogen) jacket meets IEC60332-1 fire safety standards
High Performance: Supports 10Gbps speeds up to 100 meters with 500MHz bandwidth
Durable Design: Gray LSZH jacket provides abrasion resistance and moisture protection

Technical Specifications

Parameter	Specification
Cable Type	FFTP
Category	CAT6A Ethernet Cable
Length	1000Ft
Color	Gray
Jacket Material	LSZH
Frequency	500MHz
Insulation Material	HDPE
Conductor Size	23 AWG

Detailed Construction

Component	Specification
Conductor Material	Bare Solid Copper (elongation: 19-24%)
Conductor Resistance at 20°C	≤ 9.5 Ω / 100m
Insulation Material	PE Skin-Foam-Skin
Insulation Resistance	>1500 MΩ / 100m
Characteristic Impedance	100 ± 15 Ω at 100MHz
Shielding	Pair Shield & Aluminium Foil (≥ 115% coverage)
Jacket Thickness	0.60 ~ 0.70 mm

Performance Characteristics

Frequency (MHz)	Attenuation (Max dB/100m)	NEXT (Min dB)	PS NEXT (Min dB)
100	19.13	45.30	42.30
250	31.07	39.33	36.33
500	45.26	34.82	31.82

Applications

Residential Networks

Ideal for home networking with lag-free connectivity for gaming, 4K streaming, and IoT devices. The LSZH material provides enhanced safety in residential environments.

Commercial Installations

Perfect for office environments with dense equipment, offering stable 500MHz data transmission and simplified cable management with its gray jacket.

Data Centers & Industrial

Excels in mission-critical environments with 10Gbps performance, EMI protection, and compliance with strict fire codes for data centers and industrial applications.

Frequently Asked Questions

Q: What is the brand name of this Category 6A cable?

A: The brand name is ITI-LINK.

Q: What is the model number of this CAT6A cable?

A: The model number is ITI-CTF6A-004.

Q: Where is this CAT6A cable manufactured?

A: Manufactured in SHENZHEN.

Q: What is the maximum data transfer rate?

A: Supports up to 10Gbps data transfer rates.

Q: Is this cable suitable for outdoor use?

A: No, this cable is designed for indoor applications only.

Note: All specifications are subject to change without notice. Please verify with manufacturer for latest technical details.
