| Brand Name: | ITI-LINK |
| Model Number: | ITI-CTSF7A-003 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs/day |
| Cable Type | SFTP |
| Category | CAT7A Ethernet Cable |
| Conductor Size | 23 AWG |
| Conductor Material | Copper |
| Jacket Material | PVC |
| Color | Blue |
| Frequency | 1000 MHz |
| Cable Length | 1000ft |
| Construction Item | Description |
|---|---|
| Conductor | 23 AWG bare solid copper |
| Insulation | PE Skin-Foam-Skin |
| Pair Shield | Polyester/Aluminium (PET/ALU) with ≥115% coverage |
| Braid | ɸ 0.12mm Aluminum-magnesium braided with ≥40% coverage |
| Jacket | PVC, 50P, -20~75℃ |
| Frequency (MHz) | Attenuation (Max dB/100m) | Return Loss (Min dB) | NEXT (Min dB) |
|---|---|---|---|
| 4 | 3.7 | 78.0 | 23.0 |
| 100 | 18.5 | 75.4 | 20.1 |
| 1000 | 61.9 | 60.4 | 15.1 |
