| Brand Name: | ITI-LINK |
| Model Number: | ITI-CTF8-003 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 800pcs/day |
| Cable Category | CAT8 Ethernet Cable |
|---|---|
| Jacket Color | Blue |
| Bandwidth | 2000 MHz |
| Jacket Material | PVC |
| Shielding | FTP |
| Conductor Gauge | 22 AWG |
| Conductor Material | Copper |
| Length | 1000ft |
| Construction Item | Description | Electrical Property |
|---|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) | Conductor Resistance at 20°C ≤ 5.6 Ω / 100m |
| Insulation Material | PE Skin-Foam-Skin | Insulation Resistance at 20°C >1500 MΩ / 100m |
| Pair Shield | Polyester/Aluminium (PET/ALU) ≥ 200% coverage | Characteristic impedance at 100MHz: 100 ± 15 Ω |
| Jacket Material | PVC, 50P, -20~75℃ | Dielectric Strength Test Voltage: 1.00KV DC or 0.7 KV AC for 1 min |
| Frequency (MHz) | Insertion Loss (db) | NEXT (db) | Return Loss (db) |
|---|---|---|---|
| 1 | 3.0 | 73.5 | 19.1 |
| 100 | 5.2 | 40.5 | 18.0 |
| 1000 | 17.5 | 19.3 | 8.0 |
| 2000 | 26.2 | 9.8 | 8.0 |
