Orange CAT8 Cable FFTP LSZH 22AWG 2000MHz High Speed Data Centers

Name: Orange CAT8 Cable FFTP LSZH 22AWG 2000MHz High Speed Data Centers
Brand: Integrity Cable Co., Limited
SKU: ITI-CTF8-015
Availability: InStock

Brand Name:	ITI -LINK
Model Number:	ITI-CTF8-015
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Frequency:

2000 MHz

Speed Rating:

40 Gbps

Frequency Rating:

2000 MHz

Cable Length:

50 Feet

Connector Type:

RJ45

Conductor Type:

Solid

Conductor Material:

Copper

Compatibility:

Ethernet

Shielding:

FFTP

Jacket Color:

Orange

Packaging Details:

Outer box size (for packing): 40X40X26CM

Highlight:

FFTP CAT8 cable high speed

LSZH orange CAT8 Ethernet cable

22AWG CAT8 cable 2000MHz

Product Description

Orange CAT8 Cable FFTP LSZH 22AWG 2000MHz for High-Speed Data Centers

Wholesale Bulk ITI-LINK ITI-CTF8-015 CAT8 FFTP LSZH Orange 22AWG 2000MHz Ethernet Cable - 500ft Reel for High-Speed Data Centers & Demanding Networks

ITI-LINK proudly introduces the ITI-CTF8-015, a premium CAT8 FFTP LSZH Orange Cable designed for wholesale bulk buyers and high-performance networking applications. This 500ft reel features 22AWG stranded copper conductors, a bright orange Low Smoke Zero Halogen (LSZH) jacket, and an exceptional 2000MHz bandwidth, making it ideal for high-speed data centers and rigorous industrial environments.

Unmatched Technical Specifications

22AWG Stranded Copper Conductors

The ITI-CTF8-015 CAT8 FFTP Cable utilizes 22AWG stranded copper conductors to optimize flexibility and conductivity. This design ensures smooth installation in confined spaces and minimizes signal loss, guaranteeing consistent 40Gbps/2000MHz performance.

Medium-Scale Data Centers: Simplifies cable management in server racks and reduces installation time by 35% compared to lower-grade cables.
Industrial IoT Deployments: Withstands frequent movement and bending in automated systems while maintaining signal integrity over 25,000+ flex cycles.

FFTP Shielding for Superior EMI Protection

With advanced Foil Filled Twisted Pair (FFTP) shielding, this CAT8 FFTP LSZH Orange Cable delivers unmatched resistance to electromagnetic interference (EMI) and crosstalk:

High-Interference Environments: Blocks 99.9% of EMI from heavy machinery, power generators, and HVAC systems in industrial settings.
Data Center High-Density Zones: Ensures zero signal degradation near power sources and electrical equipment, even in crowded server rooms.

2000MHz Bandwidth & LSZH Orange Jacket

2000MHz Ultra-Bandwidth: Supports 25G/40GBASE-T and future 100G applications over distances up to 30 meters, ideal for AI workloads, cloud storage, and real-time data processing.
Orange LSZH Jacket: Complies with IEC 60332-1 fire safety standards, emitting low smoke and no toxic halogens. The vibrant orange jacket improves visual identification and reduces misconnection errors by 45% in complex network setups.

Bulk Selling Advantages

Volume Discounts: Save up to 55% on orders of 500+ reels, with additional discounts for orders exceeding 1,500 reels.
Custom Branding Options: Add your company logo or custom labeling to the LSZH Orange Cable for enhanced brand promotion.
Rigorous Quality Assurance: Each reel is 100% tested for attenuation, return loss, and shielding effectiveness, and comes with ISO 11801 certification.
Flexible Logistics: Phased delivery options and customizable reel counts (500ft per reel) to align with project timelines and reduce storage costs.

Technical Parameters

Construction Item Description	Electrical Property
Conductor Material	Bare Solid Copper (elongation: 19-24%)
Conductor Resistance at 20°C	≤ 5.6 Ω / 100m
Resistance unbalance within a pair	≤ 0.2%
Insulation Material	PE Skin-Foam-Skin
Insulation Resistance at 20°C	>1500 MΩ / 100m
Mutual capacitance	5600 pF / 100m MAX
Capacitance unbalance pair to ground	≤ 160 pF / 100m
Characteristic impedance at 100MHz	100 ± 15 Ω

Applications

Optimized for Demanding High-Speed Applications

AI/ML Cluster Networks: Enables rapid data transfer between GPU/CPU server racks, reducing distributed training times for large-scale neural networks by up to 30% compared to lower-grade cabling.
Financial Trading Infrastructures: Delivers ultra-low-latency connectivity for high-frequency trading (HFT) systems, ensuring signal transmission speeds of under 1ms critical for algorithmic trading operations.
Cloud and Hyperscale Data Centers: Supports massive multi-user 8K video streaming, virtualized workloads, and high-density VM deployments without packet loss or latency spikes.

Industrial & Outdoor Deployments

Industrial IoT and Smart Manufacturing: Connects robotic controllers, vision systems, and PLCs across automotive assembly lines, maintaining 40Gbps speeds despite proximity to high-noise machinery.
Energy and Utility Monitoring: Deployed in substations and renewable energy farms (e.g., solar/wind), where the cable's LSZH orange jacket offers high visibility and resistance to UV/weathering.
Harsh Environment Networking: Suitable for petrochemical plants, shipping logistics hubs, and wastewater treatment facilities thanks to its resistance to oils, acids, and wide temperature ranges (-40°C to 75°C).

Why Choose Our CAT8 FFTP LSZH Orange Cable for Your Projects?

2000MHz Bandwidth: Ready for 25G/40GBASE-T and future 100G Ethernet.
Full FFTP Shielding: Maximum protection against EMI/RFI in noisy environments.
LSZH Orange Jacket: Improves safety and simplifies cable identification.
Bulk 500ft Reels: Ideal for large installations—reduce cost and waste.
ITI-LINK Certified: Fully compliant with ISO/IEC 11801, TIA-568-C.2-1.
