| Brand Name: | ITI-LINK |
| Model Number: | ITI-CTF8-007 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
High-performance CAT8 Ethernet cable featuring 2000 MHz bandwidth, 22AWG stranded copper conductors, and FTP shielding for superior data transmission in demanding network environments.
| Cable Category | CAT8 LAN Cable |
| Jacket Material | PVC |
| Jacket Color | Blue |
| Length | 50 meters |
| Conductor Material | Copper |
| Conductor Gauge | 22AWG |
| Shielding | FTP |
| Bandwidth | 2000MHz |
| Property | Standard | Value |
|---|---|---|
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 5.6 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 0.2% |
| Dielectric Strength Test Voltage | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
