| Brand Name: | ITI-LINK |
| Model Number: | ITI-CABLE-002 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Construction Item | Description | Electrical Property |
|---|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) | Conductor Resistance at 20°C ≤ 9.5 Ω/100m |
| Conductor OD | 24 AWG | Resistance unbalance within a pair ≤ 2% |
| Insulation Material | HDPE 8303 | Insulation Resistance >1500 MΩ/100m |
| Insulation OD | 0.90 ± 0.01 mm | Mutual capacitance 5600 pF/100m MAX |
| Color Coding | 1p: white+blue stripes, 2p: white+orange stripes, 3p: white+green stripes, 4p: white+brown stripes | Capacitance unbalance ≤ 160 pF/100m |
| Jacket Material | LSZH, 60P, -20~75℃ | Characteristic impedance 100 ± 15 Ω |
| Frequency (MHz) | Attenuation (Max dB/100m) | Propagation Delay (ns/100m) | Return Loss (Min dB) | NEXT (Min dB) |
|---|---|---|---|---|
| 4 | 4.05 | 552 | 23.01 | 56.27 |
| 10 | 6.47 | 545.38 | 25 | 50.3 |
| 25 | 10.42 | 541.2 | 24.32 | 44.33 |
| 100 | 21.98 | 537.6 | 20.11 | 35.3 |
