| Brand Name: | ITI-LINK |
| Model Number: | ITI-CABLE-004 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Construction Item | Description | Electrical Property |
|---|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) | Conductor Resistance at 20°C: ≤ 9.5 Ω/100m |
| Conductor Size | 24 AWG | Resistance unbalance within a pair: ≤ 2% |
| Insulation Material | HDPE 8303 | Insulation Resistance: >1500 MΩ/100m |
| Insulation OD | 0.90 ± 0.01 mm | Mutual capacitance: 5600 pF/100m MAX |
| Jacket Material | PVC, Rated 60 or 75℃ | Characteristic impedance at 100MHz: 100 ± 15 Ω |
| Frequency (MHz) | Attenuation (Max dB/100m) | Propagation Delay (MAX ns/100m) | NEXT (Min dB on 100m) |
|---|---|---|---|
| 4 | 4.05 | 552 | 56.27 |
| 10 | 6.47 | 545.38 | 50.30 |
| 20 | 9.27 | 542.05 | 45.78 |
| 100 | 21.98 | 537.60 | 35.30 |
