| Brand Name: | ITI-LINK |
| Model Number: | ITI-CABLE-007 |
| MOQ: | 1000pcs |
| Price: | $50-100/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Construction Item | Description | Electrical Property |
|---|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) | Conductor Resistance at 20°C ≤ 9.5 Ω/100m |
| Conductor Size | 24 AWG | Resistance unbalance within a pair ≤ 2% |
| Insulation Material | HDPE 8303 | Insulation Resistance >1500 MΩ/100m |
| Insulation OD | 0.86 ± 0.05 mm | Mutual capacitance 5600 pF/100m MAX |
| Jacket Material | Inner: PVC + Outer: PE | Characteristic impedance 100 ± 15 Ω |
| Frequency (MHz) | Attenuation (Max dB/100m) | Propagation Delay (ns/100m) | NEXT (Min dB) |
|---|---|---|---|
| 4 | 4.05 | 552 | 56.27 |
| 10 | 6.47 | 545.38 | 50.3 |
| 20 | 9.27 | 542.05 | 45.78 |
| 100 | 21.98 | 537.6 | 35.3 |
