100MHz CAT5e UTP Outdoor Network Cable 1000FT 24AWG Solid PE Waterproof Cable

Brand Name:	ITI-LINK
Model Number:	ITI-CABLE-009
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Color:

BLACK

Data Transfer Rate:

100 Mbps

Length:

1000 Ft

Jacket Material:

Frequency:

100 MHz

Application:

100Base-TX/100Base-T4/100VG-AnyLan/ATM

Cable Type:

UTP

Conductor Size:

24 AWG

Certifications:

UL, ETL, RCM, CPR, CSA

Conductor AMaterial:

Bare Copper

Packaging Details:

Color Box+Packing Box 36*36*21cm

Highlight:

CAT5e Outdoor Network Cable

100MHz Outdoor Network Cable

24AWG cat 5e 100 mhz

Product Description

100MHz CAT5e UTP Outdoor Network Cable 1000FT 24AWG Solid PE Waterproof Cable

Product Overview

This Category 5e outdoor single-layer waterproof network cable provides 100MHz bandwidth within a range of 90 meters, with a typical application speed of 100Mbps. The cable uses high-quality oxygen free copper as the transmission conductor for reliable electrical performance, making it ideal for outdoor short distance terminal wiring operations.

Key Features

Bare solid copper conductor (24AWG)
100MHz bandwidth capacity
PE waterproof jacket (60P, -20~75℃ operating range)
Compliant with ANSI/TIA-568-B.2 & ISO/EC11801 standards
Certifications: CE, RoHS, TUV, UL, CPR, ETL, RCM, ISO9001
Excellent waterproof performance for outdoor environments
Suitable for overhead or wall mounting

Technical Specifications

Construction	Description
Conductor Material	Bare Solid Copper (elongation: 19-24%)
Conductor Resistance at 20°C	≤ 9.5 Ω / 100m
Insulation Material	HDPE 8303
Insulation Resistance	>1500 MΩ / 100m
Mutual Capacitance	5600 pF / 100m MAX
Characteristic Impedance	100 ± 15 Ω at 100MHz
Jacket Material	Inner Jacket: PVC + Outside Jacket: PE
Operating Temperature	-30℃ to +50℃ (installation), -20℃ to 75℃ (operation)

Transmission Properties

Frequency (MHz)	Attenuation (Max dB/100m)	Propagation Delay (ns/100m)	NEXT (Min dB)
4	4.05	552	56.27
10	6.47	545.38	50.3
25	10.42	541.2	44.33
100	21.98	537.6	35.3

Installation Guidelines

Inspect the product upon receipt for correct printing and clear meter marks
Follow wiring standards strictly - avoid bundling or excessive bending
Use T568B or T568A standards when making RJ45 connectors
Maintain wiring distance under 100 meters for optimal performance
Install within -30 to 50℃ temperature range

Applications

This Cat5e outdoor PE network cable is ideal for:

Intelligent community monitoring systems
Smart city infrastructure (traffic signals, public WiFi, lighting)
Outdoor LAN wiring and horizontal work areas
High-speed network connections in harsh weather conditions

Its UV resistance, weatherproof properties, and waterproof design ensure reliable performance in outdoor environments.

Frequently Asked Questions

Q1. Can I order samples of LAN cables?

A: Yes, we welcome sample orders to test and check quality.

Q2. What about the lead time?

A: 3-5 days for sample preparation, 15-45 days for mass production.

Q3. Do you have a minimum order quantity?

A: Low MOQ, 1pc for sample checking is available.

Q7: What scenarios are Category 5e outdoor network cables suitable for?

A: Cat5e outdoor network cables are suitable for high-speed network applications in outdoor environments, with excellent moisture resistance to ensure stable connections.
