| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT5U-004 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Parameter | Value |
|---|---|
| Length | 1000 Feet |
| Conductor Size | 24 AWG |
| Color | Grey |
| Jacket Material | PVC |
| Component | Specification |
|---|---|
| Conductor Material | Bare Solid Copper |
| Insulation Material | HDPE 8303 |
| Jacket Material | PVC, Rated 60 or 75℃ |
| Pair Twist Configuration | Variable lay lengths for reduced crosstalk |
| Property | Value |
|---|---|
| Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m |
| Insulation Resistance | >1500 MΩ / 100m |
| Characteristic Impedance at 100MHz | 100 ± 15 Ω |
| Frequency (MHz) | Attenuation (Max dB/100m) | NEXT (Min dB) |
|---|---|---|
| 4 | 4.05 | 56.27 |
| 100 | 21.98 | 35.3 |
