24 AWG 100MHz CAT5E FTP CAT5E Cable Outdoor PE 0.47mm Solid Copper Pass Fluke 1000Ft

24 AWG 100MHz CAT5E FTP CAT5E Cable Outdoor PE 0.47mm Solid Copper Pass Fluke 1000Ft

Brand Name: ITI-LINK
Model Number: ITI-CT5F-007
MOQ: 1000pcs
Payment Terms: T/T
Supply Ability: 2000pcs/day
Detail Information
Place of Origin:
SHENZHEN
Certification:
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Conductor Size:
24 AWG
Color:
BLACK
Jacket Material:
PE
Cable Type:
FTP
Conductor Material:
Copper
Length:
1000ft
Frequency:
100MHz
Certifications:
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Packaging Details:
Color Box+Packing Box 38*38*24cm
Highlight:

24 AWG FTP CAT5E Cable

,

100MHz FTP CAT5E Cable

,

0.47mm ftp4 cat5e 24awg

Product Description
24 AWG 100MHz CAT5E FTP CAT5E Cable Outdoor PE 0.47mm Solid Copper Pass Fluke 1000Ft
CAT5E FTP Outdoor PE Cable 0.47mm Solid Copper Pass Fluke 1000FT
This Category 5E F/UTP 24AWG Solid Outdoor PE Cable features a 24AWG solid conductor structure with polyethylene (PE) jacket material, making it ideal for outdoor environments.
  • UL, ETL, and RoHS certified for safety and performance compliance
  • Foil shield provides superior protection against electromagnetic interference
  • Ideal for industrial environments and urban areas with high interference
  • Red sheath for easy identification with 24AWG solid core for reliable signal transmission
Technical Specifications
Certifications UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Jacket Material PE
Cable Type FTP CAT5E Solid Outdoor Cable
Conductor Size 24 AWG
Length 1000ft
Frequency 100MHz
Conductor Material Copper
Color Black
Construction & Electrical Properties
Conductor Material: Bare Solid Copper (elongation: 19-24%)
Conductor Resistance: ≤ 9.5 Ω / 100m at 20°C
Insulation Material: HDPE 8303
Insulation Resistance: >1500 MΩ / 100m
Characteristic Impedance: 100 ± 15 Ω at 100MHz
Transmission Properties
Frequency (MHz) Attenuation (Max dB/100m) Propagation Delay (MAX ns/100m) Return Loss (Min dB) NEXT (Min dB)
4 4.05 552 45 56.27
10 6.47 545.38 25 50.3
25 10.42 541.2 24.32 44.33
100 21.98 537.6 20.11 35.3
Applications
  • Outdoor network installations in parks, campuses, and residential areas
  • Large-scale installations in office buildings, schools, and data centers
  • High-speed data transfer for streaming, gaming, and file sharing
  • Connecting network devices in industrial environments
24 AWG 100MHz CAT5E FTP CAT5E Cable Outdoor PE 0.47mm Solid Copper Pass Fluke 1000Ft 0
Frequently Asked Questions
Q: What is the model number of this product?
A: The model number is ITI-CT5F-007.
Q: Where is this product manufactured?
A: Manufactured in SHENZHEN.
Q: What type of cable is this?
A: FTP CAT5E Outdoor PE+PVC Network cable.
Q: What is the length of this cable?
A: Standard length is 1000ft (check product packaging for variations).
