| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT5F-024 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Parameter | Standard | Value |
|---|---|---|
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
| Dielectric Strength | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| No. | Frequency (MHz) | Attenuation (Max) (dB/100m) | Propagation Delay (MAX) (ns/100m) | Return Loss (Min) (dB) | NEXT (Min) (dB) |
|---|---|---|---|---|---|
| 1 | 1 | 4 | 552 | 45 | 56.27 |
| 2 | 2 | 5.77 | 546.73 | 45 | 51.75 |
| 3 | 10 | 6.47 | 545.38 | 45 | 50.3 |
| 4 | 16 | 8.25 | 543 | 45 | 47.24 |
| 5 | 20 | 9.27 | 542.05 | 45 | 45.78 |
| 6 | 25 | 10.42 | 541.2 | 45 | 44.33 |
| 7 | 31.25 | 11.72 | 540.44 | 45 | 42.88 |
| 8 | 50 | 15.07 | 539.09 | 45 | 39.82 |
| 9 | 62.5 | 16.99 | 538.55 | 45 | 38.36 |
| 10 | 100 | 21.98 | 537.6 | 45 | 35.3 |
