0.47mm Copper Grey Jacket 1000Ft Cat5e FTP LSZH Network Cable

Name: 0.47mm Copper Grey Jacket 1000Ft Cat5e FTP LSZH Network Cable
Brand: Integrity Cable Co., Limited
SKU: ITI-CT5F-006
Availability: InStock

Brand Name:	ITI-LINK
Model Number:	ITI-CT5F-006
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Length:

1000ft

Jacket Material:

LSZH

Frequency:

100MHz

Certifications:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Conductor Material:

Copper

Conductor Size:

24 AWG

Cable Type:

FTP

Color:

Gray

Packaging Details:

Color Box+Packing Box 38*38*24cm

Highlight:

0.47mm patch cable utp cat5e

1000Ft patch cable utp cat5e

24AWG cable ftp cat 5e

Product Description

0.47mm Copper Grey Jacket 1000Ft Cat5e FTP LSZH Network Cable

Product Overview

The Cat5e shielded LSZH cable is a high-performance network transmission cable featuring a shielding design that effectively reduces electromagnetic interference for stable, high-speed data transmission. With LSZH (Low Smoke Zero Halogen) characteristics, it generates minimal smoke and toxic gases when exposed to fire or high temperatures, making it ideal for environments with strict fire safety requirements.

Key Features

FTP (Foiled Twisted Pair) shielded design for superior EMI protection
LSZH jacket material for enhanced fire safety
24 AWG solid bare copper conductors for reliable signal transmission
Supports frequencies up to 100MHz
1000ft continuous length for large installations
Certified to UL, ETL, CSA, RCM, TUV, CPR, CE, and RoHS standards

Technical Specifications

Parameter	Value
Cable Type	FTP
Length	1000ft
Color	Gray
Frequency	100MHz
Jacket Material	LSZH
Conductor Material	Copper
Conductor Size	24 AWG (0.47mm)

Electrical Properties

Property	Value
Conductor Resistance at 20°C	≤ 9.5 Ω / 100m
Resistance unbalance within a pair	≤ 2%
Insulation Resistance	>1500 MΩ / 100m
Mutual capacitance	5600 pF / 100m MAX
Characteristic impedance at 100MHz	100 ± 15 Ω

Applications

High-speed Ethernet networks (up to 1Gbps)
Data centers and server rooms
Industrial environments with EMI concerns
Commercial and residential networking
High-bandwidth applications like media streaming and online gaming

Frequently Asked Questions

Q: What is the brand name of this FTP CAT5E cable?

A: The brand name of this cable is ITI-LINK.

Q: What is the model number of this cable?

A: The model number of this cable is ITI-CT5F-006.

Q: Where is this cable manufactured?

A: This cable is manufactured in SHENZHEN.

Q: What is the maximum transmission speed of this cable?

A: The maximum transmission speed of this cable is 1000Mbps.

Q: What is the length of this cable?

A: The length of this cable varies depending on the product option selected by the customer.

Q: Do you have a minimum order quantity limit for network cable orders?

A: Low MOQ, 1000PCS for sample checking is available.

Q: How do you ship the goods and how long does it take to arrive?

A: We usually ship by sea, which usually takes about 7 days to arrive.

Q: How to proceed an order for network cable?

A: 1. Firstly let us know your requirements or application.
2. Secondly We quote according to your requirements or our suggestions.
3. Thirdly customer confirms the samples and places deposit for formal order.
4. Fourthly We arrange the production.
