1000ft CAT6 UTP High Speed Network Cable 1Gbps With Special For Project

Name: 1000ft CAT6 UTP High Speed Network Cable 1Gbps With Special For Project
Brand: Integrity Cable Co., Limited
SKU: ITI-CT6U-0015
Availability: InStock

Brand Name:	ITI-LINK
Model Number:	ITI-CT6U-0015
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Color:

Blue

Transmission Speed:

1Gbps

Certifications:

UL, ETL, RCM, CPR, CSA

Category:

CAT6

Bandwidth:

250MHz

Conductor Size:

23AWG

Jacket Material:

PVC

Application:

100Base-TX/100Base-T4/100VG-AnyLan/ATM

Packaging Details:

Wooden shaft packaging：38x26x22cm

Highlight:

1000ft high speed network cable

CAT6 high speed network cable

UTP high speed cat 6 cable

Product Description

1000ft CAT6 UTP High Speed Network Cable 1Gbps With Special For Project

Premium CAT6 UTP Network Cable for Large-Scale Projects

This 1000ft UTP CAT6 cable is engineered for professional network installations, delivering superior performance for enterprise networks and infrastructure upgrades. The blue PVC outer sheath features high-grade flame-retardant materials for enhanced safety.

Key Features

23AWG oxygen-free copper conductors for superior signal transmission
Cross skeleton design minimizes electromagnetic interference
Supports 10 Gigabit Ethernet over short distances
250MHz bandwidth (extendable to 550MHz)
Standard 1Gbps transmission rate with stable performance

Technical Specifications

Construction	Electrical Properties
Conductor: 23AWG bare solid copper	Conductor resistance: ≤9.5Ω/100m
Insulation: HDPE 8303	Insulation resistance: >1500MΩ/100m
Jacket: PVC + PE	Characteristic impedance: 100±15Ω
Color-coded twisted pairs	Dielectric strength: 1.00KV DC

Transmission Performance

Frequency (MHz)	Attenuation (Max dB/100m)	NEXT (Min dB)
100	19.8	45.3
250	32.85	40.35
500	31.85	40.23

Applications

Enterprise network infrastructure
Data center cabling
Office and home networks
Audio/video systems
Digital signage installations

Frequently Asked Questions

Q1. What is the brand name of the UTP CAT6 Cable?

A1. The brand name is ITI-LINK.

Q2. What certifications does the cable have?

A2. Certified by UL, ETL, CSA, RCM, TUV, CPR, CE, and RoHS.

Q3. Can CAT6 pass the link test?

A3. Our product has passed 90 meter link tests and network segmentation tests.
