Resistant Abrasion CAT6 UTP Low Smoke Zero Halogen Cable For Network Deployments

Name: Resistant Abrasion CAT6 UTP Low Smoke Zero Halogen Cable For Network Deployments
Brand: Integrity Cable Co., Limited
SKU: ITI-CT6U-023
Availability: InStock

Brand Name:	ITI -LINK
Model Number:	ITI-CT6U-023
MOQ:	1000pcs
Payment Terms:	T/T
Supply Ability:	2000pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Certification:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Conductor Amaterial:

Bare Copper

Cable Type:

Solid

Jacket Material:

LSZH

Operating Temperature:

-20°C To 60°C

Shielding:

Foil

Conductor Size:

23 AWG

Cable Length:

500FT

Certifications:

UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Packaging Details:

Inner box size: 32 cm (length) × 32 cm (width) × 18.5 cm (height) Outer box size (for packing): 39 cm (length) × 33.5 cm (width) × 34 cm (height)

Highlight:

Zero Halogen CAT6 UTP Cable

CAT6 UTP resistant abrasion

CAT6 UTP Low Smoke Cable

Product Description

Resistant Abrasion CAT6 UTP Low Smoke Zero Halogen Cable For Network Deployments

Wholesale Bulk CAT6 UTP Low-Smoke Zero-Halogen Cable for High-Speed Network Deployments

The ITI-LINK ITI-CT6U-023 is a premium CAT6 UTP Low-Smoke Zero-Halogen (LSZH) Ethernet cable engineered for wholesale buyers and large-scale network projects. With a 500FT reel, 23AWG oxygen-free copper conductors, and UTP (Unshielded Twisted Pair) design, this cable delivers 250MHz bandwidth and 10Gbps data transfer—ideal for high-speed applications like cloud computing, 4K video streaming, and enterprise LANs. The LSZH jacket ensures safety in enclosed environments, while the rugged construction supports reliable performance in demanding deployments.

LSZH Jacket: Safety Meets Durability for Bulk Installations

Featuring a low-smoke zero-halogen (LSZH) jacket, the ITI-CT6U-023 CAT6 UTP cable offers critical advantages for large-scale setups:

Fire Safety Compliance: Emits minimal toxic fumes and zero halogen gases, meeting international standards (e.g., IEC 61034) for commercial buildings, data centers, and residential complexes.
Environmental Resistance: Protects against moisture, UV rays, and moderate chemical exposure, ensuring longevity in both indoor and outdoor conduit installations.
Sleek Aesthetics: Neutral jacket design blends seamlessly into modern network environments, reducing visual clutter in high-density cabling scenarios.

The 500FT reel format minimizes waste and streamlines inventory management for wholesale distributors, enabling efficient scaling across thousands of network nodes.

Technical Parameters

Product Attribute	Value
Cable Type	CAT6 Network Cable
Transmission Speed	1Gbps
Bandwidth	250MHz
Color	Grey
Conductor Size	23AWG
Jacket Material	PVC
Length	500ft
Certifications	UL, ETL, RCM, CPR, CSA
Compatibility	Ethernet
Category	CAT6 LAN Cable
Shielding	Unshielded

Construction Details

Construction Item Description	Electrical Property
Conductor Material	Bare Solid Copper (elongation: 19-24%)
Conductor Resistance at 20°C	≤ 9.5 Ω / 100m
Insulation Material	HDPE 8303
Insulation Resistance at 20°C	>1500 MΩ / 100m
Mutual capacitance	5600 pF / 100m MAX
Characteristic impedance at 100MHz	100 ±15 Ω

Transmission Properties

Frequency (MHz)	Attenuation (Max) dB/100m	Propagation Delay (MAX) ns/100m	Return Loss (Min) dB	NEXT (Min) dB
1	4	3.78	45	66.27
10	5.95	545.38	25	60.3
100	19.8	537.6	20.11	45.3
250	32.85	536.28	17.32	39.33

Applications

UTP Design: Cost-Effective Performance for Non-EMI Environments

Designed for environments without heavy electromagnetic interference, the ITI-CT6U-023 leverages UTP technology to balance performance and affordability:

10Gbps Speed Support: Handles bandwidth-intensive tasks like virtualization, large-file transfers, and real-time collaboration tools across 100-meter distances.
23AWG Conductors: Thicker gauge ensures lower attenuation and stable signal transmission, critical for maintaining speed consistency in bulk network setups.
Plug-and-Play Compatibility: Works seamlessly with existing CAT5E/CAT6 infrastructure, reducing upgrade costs for enterprises migrating to high-speed networks.

Versatile Applications for Large-Scale Bulk Projects

Enterprise Networks: Connects 1000+ workstations, IP phones, and servers in multi-floor offices, supporting seamless cloud integration and video conferencing.
Data Centers & Server Rooms: Serves as horizontal cabling in mid-sized data centers, where LSZH compliance and UTP simplicity optimize rack-to-server connectivity.
Smart Buildings & Campuses: Powers IoT devices, security systems, and AV networks in smart offices, universities, and healthcare facilities.
Residential Developments: Pre-wires apartments and gated communities for gigabit internet, with 500FT reels reducing waste in large-scale housing projects.

Bulk-Ready Features for Wholesale Efficiency

Volume Discounts: 25% cost savings on orders over 100 reels, ideal for system integrators and distributors.
Logistics-Friendly Packaging: 500FT reels fit standard shipping pallets, reducing freight costs by 35% compared to smaller formats.
Factory Testing: 100% verification for 15+ performance metrics (attenuation, NEXT, return loss) to ensure batch consistency.

Frequently Asked Questions

Q: What is the brand name of this product?

A: The brand name of this product is ITI-LINK.

Q: What is the model number of this product?

A: The model number of this product is ITI-CT6U-023.

Q: Where is this product made?

A: This product is made in Shenzhen.

Q: What certifications does this product have?

A: This product is certified by UL, ETL, CSA, RCM, TUV, CPR, CE, and RoHS.

Q: What is the minimum order quantity for this product?

A: The minimum order quantity for this product is 500PCS.

Q: What is the delivery time for this product?

A: The delivery time for this product is 15-45DAYS.
