| Brand Name: | ITI -LINK |
| Model Number: | ITI-CT6U-012 |
| MOQ: | 1000pcs |
| Payment Terms: | T/T |
| Supply Ability: | 2000pcs/day |
| Compatibility | Ethernet |
| Transmission Speed | 1Gbps |
| Conductor Size | 23AWG |
| Length | 500ft |
| Jacket Material | LSZH |
| Shielding | Unshielded |
| Bandwidth | 250MHz |
| Category | CAT6 LAN CABLE |
| Certifications | UL, CSA, ETL, CPR, TUV, RCM, CE, RoHS |
| Color | Blue |
| Construction Item | Description |
|---|---|
| Conductor Material | Bare Solid Copper (elongation: 19-24%) |
| Insulation Material | HDPE |
| Pair Twist | Variable lay lengths for each pair |
| Jacket Material | LSZH, 60P, -20~75℃ |
| Jacket Hardness | 81± 3 |
| Frequency (MHz) | Attenuation (Max dB/100m) | Return Loss (Min dB) | NEXT (Min dB) |
|---|---|---|---|
| 1 | 3.78 | 45 | 66.27 |
| 100 | 19.8 | 20.11 | 45.3 |
| 250 | 32.85 | 17.32 | 39.33 |
